기록된 평범한 회전식 십자문과 15년 이상간 파킹 장치 제조!
주식 코드 :832966
| Place of Origin: | China |
|---|---|
| 브랜드 이름: | DOOR or OEM |
| 인증: | CE / IS09001 |
| Model Number: | DRTD6771-1 |
| Minimum Order Quantity: | 2 sets |
| 가격: | negotiable |
| Packaging Details: | wood carton |
| Delivery Time: | 5-7 working days |
| Payment Terms: | T/T |
| Supply Ability: | 2500 sets per month |
| Material: | 304# Stainless Steel | Suitable For: | Access Control, Entrance And Exit Control |
|---|---|---|---|
| Turnstile Material: | SUS304 Stainless | Communication Interface: | RS485 |
| Power Supply: | AC110/AC220+/-10% | Swing arm available: | Acrylics Or Tempered Glass |
| Driving Motor: | DC24V Brushless Motor | Opening Signal Input:: | Dry Contact |
| Working environment: | -25℃-+70℃ | Pass speed: | 20-35personal/min |
| Support System: | Face Recognition,ic/id Card,fingerprint | Motor: | DC24V Brushless Motor |
| IR Sensor: | 8 pairs | Passage Width: | ≤650mm |
| IP Rating: | IP65 | Mean Cycles Between Failure: | 20 million times |
| Voltage: | AC110V/AC220V±10% 50-60Hz | Operating Power: | 30W |
| Method of position: | Motor Driving | Mtbf: | 5 Million Times |
| Size: | 1530(L)*1180(W)*2310(H)(mm)Single Channel | Warranty:: | 1 Year |
| 강조하다: | 304 stainless steel full height turnstile,full height turnstile with RS485,industrial turnstile with RS485 interface |
||
| Attribute | Value |
|---|---|
| Material | 304# Stainless Steel |
| Suitable For | Access Control, Entrance And Exit Control |
| Turnstile Material | SUS304 Stainless |
| Communication Interface | RS485 |
| Power Supply | AC110/AC220+/-10% |
| Swing arm available | Acrylics Or Tempered Glass |
| Driving Motor | DC24V Brushless Motor |
| Opening Signal Input | Dry Contact |
| Working environment | -25℃-+70℃ |
| Pass speed | 20-35personal/min |
| Support System | Face Recognition, IC/ID Card, Fingerprint |
| Motor | DC24V Brushless Motor |
| IR Sensor | 8 pairs |
| Passage Width | ≤650mm |
| IP Rating | IP65 |
| Mean Cycles Between Failure | 20 million times |
| Voltage | AC110V/AC220V±10% 50-60Hz |
| Operating Power | 30W |
| Method of position | Motor Driving |
| MTBF | 5 Million Times |
| Size | 1530(L)*1180(W)*2310(H)(mm) Single Channel |
| Warranty | 1 Year |
Widely used for official or corporate buildings, sectioning off certain areas in University lab access points, industrial buildings or hospital radiology departments.
Shipping fee and delivery date to be negotiated. Contact supplier for more details.
